Welbilt Merrychef eikon e1s - Technical Data Summary

83
eikon e1s
Service and repair guide
3A. Technical data summary
Dimensions and weight
Size and weight (without packaging)
• Width of appliance = 406.4mm (16”)
• Total depth with door open = 806.9mm (31.8”)
• Depth with door closed = 538mm (21.2”)
• Counter depth = 499.0mm (19.6”)
• Net weight = 46.0 kg (101 lbs)
Safety clearances
• The minimum height of free space necessary above the top surface of the appliance is 50mm (2”).
• Safety clearance on left-/right-hand side / at rear: 0mm
Electrical specifications
See Error! Reference source not found. in Section 2B.
Power and heat
Microwave power
• Microwave settings, off or 5–100% in 1% increments
Convected heat
• Temperature settings OFF and from 100°C to 260° C / 212°F to 500°F in 1°C steps
Noise emission
The weighted emission sound pressure is <70 dBA.
Regulatory standards compliance
See Section 1: Safety for details of regulatory standards and directives.
