Welbilt Merrychef eikon e1s - Cavity Temperature Settings

67
eikon e1s
Service and repair guide
Cavity temperature settings and labels
1. Select the ‘temperature’ symbol from the
settings menu.
The temperature screen is displayed if two or
more cavity temperatures are set above the
minimum. You can now:
A) Change a temperature set
B) Edit the existing temperature labels
C) Add a new temperature
D) Change the measurement unit
A) Change a temperature set
1. Select the temperature you want to change by
tapping the value or the red temperature symbol
next to it.
2. Edit the temperature as required using the
keypad.
3. Select the checkmark to continue.
B) Edit temperature labels
1. Select the required label below the temperature.
2. Edit the label as required using the keypad
3. Select the checkmark to continue.
C) Add a new temperature
1. Select a disabled temperature option from the
screen (scroll down using arrow if required).
2. Select the temperature area marked as ‘disabled’
or the red temperature symbol.
3. Enter a temperature value using the keypad and
select the checkmark to continue.
4. Select the ‘Optional Label’ box to assign a label
to the temperature and select the checkmark to
continue.
D) Change measurement unit
You can change the temperature measurement unit
from Celsius to Fahrenheit and Fahrenheit to Celsius
by simply selecting or deselecting the unit checkbox.
