Service Manual Field Replaceable Parts 71

Table 8. ASSEMBLY, BASE CP 100/200

Part Number Description Quantity

703511 HOUSING, CP 100/CP 200 BASE 1

101-0038 GROUND PLUG, 6/25 1

620198 FOOT 4

106124-4 SCREW 4-20.250 PAN PHILLIPS 9

236732 IEC CONNECTOR 1

236733 FUSE DRAWER 1

703611 EOS MVLT80-1001-S77 PWR SUPPLY 1

703774 FERRITE, FLAT CABLE SNAP-ITS 1

104-0007 WASHER, FLAT 1

104-0008 WASHER LOCK SERRATED 4

102-0001 NUT HEX 2

401370 BATTERY ASSEMBLY, CP 100/CP 200 1

704064 BATTERY FUSE, ZEUS PC5-6 1

700015 BATTERY DOOR, CP 100/CP 200 1

703247 PHPS 6-32 X.375 (Battery Door) 2

704068 HARNESS, INCOMING PWR (W001) 1

704067 HARNESS, GROUND POWER SUPPLY (W003) 1

700157 HARNESS, PWR SUPPLY TO MAIN PCB (W002) 1

704221 HARNESS, BATTERY (W008) 1

700152 HARNESS, MAIN PCB TO KEYBOARD (W014) 1

455508 LABEL, PROTECTIVE EARTH GROUND 3

703922 FUSE, 250V, 5 X 20MM, TIME LAG 2

Table 9. ASSEMBLY PRINTER, CP 100/200

Part Number Description Quantity

700007 AUX PAPER COVER, CP 100/CP 200 1

700012 PAPER TRAY , CP 100/CP 200 1

703258 SCREW M3 X 6 PHP FH, V 2

700117 SPRING, PRINT HEAD 1

700118 SHOULDER SCREW M3 X .5 2

703246 SCREW, M3 X 0.5, PAN PHILLIPS 8

106137-1 NUT,4-40X.250 HEX,KEPS EXTLOCK 1

700160 HARNESS, GROUND PRINT HEAD (W005) 1

700161 HARNESS, PAPER DETECTION (W006) 1

700162 HARNESS, PRINT HEAD (W007) 1
