Service Manual Field Replaceable Parts 73

703854 LABEL, QUICK GUIDE, DUTCH, CP 100 1

703847 LABEL, QUICK GUIDE, FRENCH CP 100 1

703850 LABEL, QUICK GUIDE, GERMAN, CP 100 1

703852 LABEL, QUICK GUIDE, ITALIAN, CP 100 1

703853 LABEL, QUICK GUIDE, NORWEGIAN, CP 100 1

703857 LABEL, QUICK GUIDE, PORTUGUESE, CP 100 1

703851 LABEL, QUICK GUIDE, SPANISH, CP 100 1

703855 LABEL, QUICK GUIDE, SWISS, CP 100 1

Table 11. ASSEMBLY, TOP COVER, CP 200

Part Number Description Quantity

704343 HOUSING, CP 200, TOP 1

700122 DISPLAY, LCD, COLOR - 320 x 240 , 5.7" N, CP 200 1

700121 GLARE SCREEN, CP 200 1

401462 ASSY, QWERTY KEYBOARD, CP 200 1

401461 ASSY, FUNCTION KEYPAD, CP 200 1

703680 SCREW,TORX#2 x 1/4 PAN PLASTITE 13

106124-4 SCREW 4-20.250 PAN PHILLIPS 5

700119 INVERTER, LCD 1

200076-1 SCREW 0-40 .187 PAN TORX 2

106140-3 SCREW 4-40 .250 PAN PHILLIPS STEEL ZINC 4

704232 HARNESS, QWERTY BOARD TO LCD (W013) 1

700079 HARNESS, KEY BOARD TO KEYPAD BOARD(W012) 1

700151 HARNESS, INVERTER SUPPLY (W009) 1

700730 HARNESS, GRND LCD (W010) 1

700124 LABEL, QWERTY CP 200 1

703108 LABEL, FKP, ENGLISH 1

703152 LABEL, FKP, DANISH 1

703150 LABEL, FKP, DUTCH 1

703105 LABEL, FKP, FRENCH 1

701032 LABEL, FKP, GERMAN 1

703834 LABEL, FKP, ITIALIAN 1

703109 LABEL, FKP, NORWEGIAN 1

703153 LABEL, FKP, PORTUGUESE 1

703107 LABEL, FKP, SPANISH 1

703151 LABEL, FKP, SWISS 1

Table 10. ASSEMBLY, PAPER TRAY COVER, CP 100/200

Part Number Description Quantity
