Operation1203−1/A1
Winterthur Gas & Diesel Ltd.
2/ 3
I
I
9
8
7
6
1
2
3
4
018.087/09
OI
5
Fig. 1: Cross Section
1 Column 6 Arbor support
2 Oil pipe 7 Bearing cover
3 Nozzle 8 Intermediate wheel (pump unit)
4 Bedplate 9 Intermediate wheel (supply unit)
5 Thrust pad (free end) OI Bearing oil inlet
Thrust Bearing
