Operation
4003−3/A1
Winterthur Gas & Diesel Ltd.
1/ 21
Control and Auxiliary Systems
1. General
On pages 3 to 21 the full engine control with the auxiliary systems, divided into their
various functions, is shown. The data includes all interfaces to the plant and the
remote control with clear identification of the internal and external connections.
Overview of the systems Path No.
range
Page
Air supply 30 3
Bearing and cooling oil supply 40 4
Servo oil supply (2 servo oil pumps). See Note. 50 5
Servo oil supply (3 servo oil pumps). See Note. 50 6
Fuel supply (4 pumps). See Note. 60 7
Fuel supply (6 pumps). See Note. 60 8
Starting system 110 9
Speed control 150 10
Cylinder lubrication pulse (6 to 8 cylinders). See Note. 170 11
Cylinder lubrication pulse (9 cylinders). See Note. 170 12
Exhaust gas / turbocharger type TPL and MET / scavenge air / auxiliary blower
(1-stage scavenge air cooler). See Note.
300 13
Exhaust gas / turbocharger type TPL and MET / scavenge air / auxiliary blower
(2-stage scavenge air cooler). See Note.
300 14
Exhaust valve drive, air spring (6 to 8 cylinders / 2 pumps). See Note. 310 15
Exhaust valve drive, air spring (6 to 8 cylinders / 3 pumps). See Note. 310 16
Exhaust valve drive, air spring (9 cylinders / 3 pumps). See Note. 310 17
Fuel injection (6 to 8 cylinders). See Note. 330 18
Fuel injection (9 cylinders). See Note. 330 19
Cooling water 340 20
Main bearing lubrication, piston cooling, OMD 350 21
Note − Alternative design.
