Operation5583−1/A1
Winterthur Gas & Diesel Ltd.
2/ 2
1
2
3
WCH01162
1
6
2
4
5
DRAWN FOR 6 CYLINDERS
TO 8 CYLINDERS
Fig. 1: Fuel Pump Actuator
1 Fuel pump 3.14 4 Toothed rack
2 Fuel pump actuator 3.21 5 Connecting element
3 Fuel pump unit 6 Lever
2017−08
Fuel Pump Actuator
