Operation6420−1/A1
Winterthur Gas & Diesel Ltd.
2/ 3
2
6
1
II
4
3
5
WCH01159
For view II, see Fig. 2
4
4
8
7
I
I
Fig. 1: Scavenge Air Receiver
1 Auxiliary blower 5 Scavenge air receiver
2 Electric motor 6 Cover
3 Hinged cover 7 Cup springs
4 Relief valve 8 Compression spring
