Operation
8019−1/A2
Winterthur Gas & Diesel Ltd.
5/ 13
019.376/10
2
5
1
4
4
1
2
5
6
FUEL SIDE
EXHAUST SIDE
3
Fig. 3: Drain Valves
1 HP fuel pipe 4 Drain valve (fuel outlet)
2 Fuel pump 5 Drain valve (fuel inlet)
3 Level switch LS3427A 6 Level switch LS3426A
2015-05
Fuel System 9-cylinders
