Operation
0320−1/A1
Winterthur Gas & Diesel Ltd.
3/ 3
WCH01073
6
712
4
3
8
5
Fig. 1: Starting Air System
1 Shut-off valve for starting air 5 Venting valve 2.27
2 Handwheel for shut-off valve 6 Starting air manifold
3 Drain and test valve 2.06 7 Starting air valve
4 Venting valve 2.21 8 5/2-way solenoid valve
2. Procedures for Service Breaks for a Longer Period
(weeks or months)
Refer to paragraph 1.2 and to 0620−1 Procedures before Putting Out of Service for a
Long Period.
