Operation Manual simco
®
drive
Revision: 11a 4022-D033499 en-13
日本語
5.2.2 Mounting options IP65
Mounting material: 4 cylinder head screws with hexagon socket ISO 4762 - M 6 – 8.8
Required tool: Hex key AF 5
Tightening torques see Chapter 9.1 Tightening torques
5.2.3 Installation space IP65
The installation size must be sufficiently large.
A minimum distance of 25 mm on all sides of the drive amplifier must be provided.
5.2.4 Mounting position IP65
Any mounting position can be selected
5.2.5 Ventilation/cooling IP65
Sufficient convection for cooling of the drive amplifier must be ensured at the installation
location.
To avoid overheating, closed installation sites with low volume flow are not suitable for
installation of the drive amplifier.
The drive amplifier is to be mounted on a flat, metallic surface.
5.2.6 Environmental conditions for vibration/shock IP65
The drive amplifier fulfills the following specifications:
− Vibration according to DIN EN 60068-2-6:2008
o Frequency range 10 Hz – 150 Hz
o Acceleration: 5 g
− Shock according to DIN EN 60068-2-27:2010
o Shock form: Semi-sinusoidal
o Acceleration: 50 g
o Duration of the shock: 11 ms
