Wittenstein cyber motor simco SIM2002D - X1: Resolver; X2: Digital Inputs

Operation Manual simco
®
drive
Revision: 11a 4022-D033499 en-19
deutsch
english
français
italiano
español
日本語
6.3.3 X1: Resolver
Figure
Pin
no.
Signal
name
Function
Input/output
1
COS+
Cosine trace S1
Input
2
COS-
Cosine trace S3
Input
3
SIN+
Sine trace S2
Input
4
SIN-
Sine trace S4
Input
5
REF+
Reference trace R1
Output
6
REF-
Reference trace R2
Output
7
N.C.
8
N.C.
Plug type on drive amplifier: M12, 8-pin, female, A-coded
Connection
Properties
Unit
Minimum
value
Nominal
value
Maximum
value
Reference trace
Excitation frequency
kHz
10
Output voltage
Vpk
4
5
5,5
Output current
mA
30
Sine/cosine
Input resistance
kOhm
100
Input voltage
Vpk
2,5
5
Resolution
Bit
10
12
14
6.3.4 X2: Digital inputs
• An external reference potential most be connected to supply the digital outputs.
− The digital inputs are galvanically isolated from the logic and power of the drive
amplifier.
Figure
Pin
no.
Signal name
Function
Input/output
1
DIN1
Digital input 1
Input
2
DIN2
Digital input 2
Input
3
DIN3
Digital input 3
Input
4
DIN4
Digital input 4
Input
5
GND
Reference
ground
Plug type on drive amplifier: M12, 5-pin, female, B-coded
Connection
Properties
Unit
Minimum
value
Nominal
value
Maximum
value
DINx
Input voltage
V DC
20
24
28
Input current
mA DC
3
4
5
Input resistance
kOhm
5,6
Sample time
msec
1
GND
Reference ground
