Wolf RM-2 - Specification; Technical Specifications Overview

Appendix
3066510_202108 WOLF GmbH | 55
10.6 Specication
Description RM-2 RM-2 Wireless
IP rating IP20 IP20
Protection class III III
Operating voltage 9-24 VDC
(eBus)
4.5 V batteries
(3 x AAA) or
9 VDC power
supply unit
Battery type - Alkaline
Battery life - 1 - 1.5 years
1)
(depending on
use)
Ambient temperature in operation 0...60 C° 0...60 C°
Storage temperature -30...70 C° -30...70 C°
Humidity during operation
(non-condensing)
20...90% rel. 20...90% rel.
Max. current drawn 40 mA 40 mA
Wireless frequency - 868 MHz
Range - Open-air space
50 m
In building: 30 m
Time switch power backup 48 h 48 h
Communication and power supply
via 2-core cable
0.5...0.8
mm²
-
Contamination level 2 2
Temperature for the ball pressure
test
75 °C 75 °C
1) Guidance: The RM-2 Wireless will be active for around 1 minute per day! WOLF
recommends using high-quality batteries (long-life, etc.).
