6-S3
L3130 · L3430 · L3830 · L4630 · L5030, WSM
FRONT AXLE
(Continued)
W10138740
Item Factory Specification Allowable Limit
(for L3130, L3430, L3830 and L4630)
Spiral Bevel Pinion Shaft to Spiral Bevel
Gear
Backlash 0.1 to 0.3 mm
0.004 to 0.012 in.
–
(for L5030)
Spiral Bevel Pinion Shaft to Spiral Bevel
Gear
Backlash 0.2 to 0.3 mm
0.008 to 0.012 in.
–
Bevel Gear to Bevel Gear Backlash 0.15 to 0.35 mm
0.006 to 0.014 in.
0.6 mm
0.024 in.
Front Axle Case Boss (Front) to Bracket
Bushing
Front Axle Case Boss (Front)
Bushing
Clearance
O.D.
I.D.
0.120 to 0.275 mm
0.00472 to 0.01083 in.
49.950 to 49.975 mm
1.96653 to 1.96752 in.
50.095 to 50.225 mm
1.97224 to 1.97736 in.
0.50 mm
0.19685 in.
–
–
(for L3130, L3430, L3830 and L4630)
Front Axle Case Boss (Rear) to Bracket
Bushing
Front Axle Case Boss (Rear)
Bushing
Clearance
O.D.
I.D.
0.100 to 0.292 mm
0.00394 to 0.01150 in.
69.970 to 70.000 mm
2.75472 to 2.75590 in.
70.100 to 70.262 mm
2.75984 to 2.76622 in.
1.0 mm
0.03937 in.
–
–
(for L5030)
Front Axle Case Boss (Rear) to Bracket
Bushing
Front Axle Case Boss (Rear)
Bushing
Clearance
O.D.
I.D.
0.025 to 0.195 mm
0.00098 to 0.00768 in.
80.000 to 80.035 mm
3.14961 to 3.15098 in.
80.060 to 80.195 mm
3.15197 to 3.15728 in.
0.5 mm
0.19685 in.
–
–
(for L5030)
Bevel Gear Case Boss to Front Axle
Support Bushing
Bevel Gear Case Boss
Front Axle Support Bushing
Clearance
O.D.
I.D.
0.080 to 0.232 mm
0.00315 to 0.00913 in.
54.970 to 55.000 mm
2.16417 to 2.16535 in.
55.080 to 55.202 mm
2.16850 to 2.17331 in.
1.0 mm
0.03937 in.
–
–
KiSC issued 02, 2007 A
