Multi 3430 Operation
35
ba75865e08 06/2010
4.5 Channel display
The Multi 3430 manages the connected sensors and displays which
sensor is plugged to which connection.
2 Display further sensor data (settings) with [More].
30.09.2009 08:00More
SenTix 940
B092500013
30.09.2009 08:00
Man. temperature: 25 °C
pH resolution 0.001
mV resolution 0.1
Buffer TEC
Calibration interval 7d
Unit for slope mV/pH
QSC:
SenTix 940
B092500013
30.09.2009 08:00Info
Channel display
Display of the plug position
for the respective parameter
The red bar indicates for
each connected sensor to
which plug position of the
meter it is connected.
