Dissolved oxygen Multi 9310
54 ba75937e03 12/2011
7.3.6 Calibration data
Displaying the
calibration record
The calibration record of the last calibration is to be found under the menu item,
Calibration / Calibration record. To open it in the measured value display, press
the <CAL__> key.
The calibration records of the last 10 calibrations are to be found in the menu,
Calibration/Calibration data storage / Display. To open the Calibration menu,
press the <ENTER> key in the measured value display.
4. Start the measurement with <ENTER>.
The measured value is checked for stability (stability control).
The [AR] status indicator is displayed. The measured parameter
flashes.
5. Wait for the end of the AutoRead measurement or accept the calibration
value with <ENTER>.
The factor that was set last is displayed.
6. Using <
><
>, set the correction factor to adjust the displayed con-
centration value to the nominal value (value of the comparison mea-
surement). Subsequently, accept the correction factor with <ENTER>.
The measuring instrument switches to the measured value display.
The status display [Factor] is active.
The calibration record is automatically transmitted to the interface
after calibrating.
O
2
7.92
mg/l
0.973
FDO Comp
22.09.2008
08:00
