Xerox B1025 System Administrator Guide

Setting Access Rights
You can control access to services and features by setting up authentication and authorization.
Personalization allows the printer to retrieve user information to customize features.
AAuutthheennttiiccaattiioonn
Authentication is the process of confirming user identities. If you enable authentication, the printer
compares the information that users provide to another source of information, such as an LDAP
directory. If the information is valid, the users are considered authenticated.
There are several ways to authenticate a user:
• Passcode: This option enables a passcode. To access the printer, at the control panel, users type a
passcode. The printer compares the passcode to the stored information.
•
Local Authentication: The option
enables local authentication. To prove their identity, users type
their user name and password at the control panel or in Xerox
®
CentreWare
®
Internet Services.
The printer compares the user credentials to the information stored in the user database. If you
have a limited number of users, or do not have access to an authentication server, use this
authentication method.
• Network Authentication: This option enables network authentication. To prove their identity,
users type their user name and password at the control panel or in Xerox
®
CentreWare
®
Internet
Services. The printer compares the user credentials to the information stored on an authentication
server.
Note: The printer can use one of the following authentication server types:
• Kerberos for UNIX, Linux, or Windows ADS
• SMB for Windows ADS or LDAP
SSeettttiinngg tthhee LLooggiinn MMeetthhoodd
1. In Xerox
®
CentreWare
®
Internet Services, click Properties→Login / Permissions.
2. Click Login Methods.
3. To set the authentication method, select an option:
• No Authentication: This option allows unrestricted access to the printer.
• Passcode: This option creates the passcode for users to enter on the control panel. For Create
Passcode, type a password.
• Local Authentication: This option stores user login information on the printer in the Device
User Database. To configure the database, for Device User Database, click the Pencil icon.
• Network Authentication: This option stores user login information on an authentication
server in the network. To configure the server connection, for Authentication Server, click the
Pencil icon.
Note: If you select Local Authentication or Network Authentication, you can set the printer
to retrieve user profile information from LDAP. To retrieve information from LDAP, for
Personalize Touch UI, select Retrieve Profile Information for Authenticated User from
LDAP. To configure the server connection, for LDAP Server, click the Pencil icon.
44
Xerox
®
B1025 Multifunction Printer
System Administrator Guide
Security

Xerox B1025 Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Booklet printing function	Yes
Print speed (black, normal quality, A4/US Letter)	25 ppm
Duplex print speed (black, normal quality, A4/US Letter)	13 ppm
PCL fonts	107
Printer fonts	PCL, PostScript
Digital sender	-
Maximum duty cycle	50000 pages per month
Recommended duty cycle	2000 - 50000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 6, PostScript
Compatible memory cards	MicroSD (TransFlash)
Maximum internal memory	1536 MB
Sound pressure level (quiet mode)	30 dB
Wi-Fi	No
Security features	Firmware Verification, Security Certificate Management, Signed Certificate Creation, Audit Log
Cabling technology	10/100Base-T(X)
Security algorithms	AES, FIPS 140-2, SNMPv3, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
AC input voltage	110 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (off)	2 W
Power consumption (sleep)	1.5 W
Power consumption (average operating)	650 W
Energy Star Typical Electricity Consumption (TEC)	1.65 kWh/week
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Package depth	750 mm
Package width	771 mm
Package height	600 mm
Package weight	32300 g
Scan to	E-mail, FTP, SMB, USB
Scan drivers	TWAIN, WIA
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Scan speed (color)	30 ppm
Image formats supported	JPEG, TIFF
Document formats supported	PDF
Optical scanning resolution	600 x 600 DPI
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Other operating systems supported	Solaris 11
Mobile operating systems supported	Android
Server operating systems supported	Windows 2000 Server, Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Copier resize	25 - 400 %
Time to first copy (black, normal)	7.6 s
Copy speed (black, normal quality, A4)	25 cpm
Modem speed	33.6 Kbit/s
Total input capacity	100 sheets
Total output capacity	250 sheets
Product color	Black, White
Market positioning	Business
Paper tray media types	Bond paper, Heavy paper, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper, Thin paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3

Weight and Dimensions

Depth	555.3 mm
Width	560 mm
Height	417 mm
