2.1 Main Components and Functions 35
Control Panel
No. Name Description
1 LCD display Displays the status of the printer, menu options, and messages.
Refer to
• "Control Panel Display" (P. 36)
2 <Menu> button Pressed to display the menu screen.
3 <Eject/Set> button Pressed to confirm the menu option selected on the menu screen. This button
is used also when printing reports/lists.
4
<Power Saver> button/lamp
Pressed to exit the Power Saver mode (Sl
eep mode). This button/la
mp lights
when the printer is the Power Saver mode (Sleep mode).
5 <Cancel Job> button Pressed to stop printing.
6
< >, < >, < >, < >
button
Pressed to advance to the next menu, item, or option.
The < > button is used also when using the Secure/Sample Print feature.
Note
• Holding down the < > or < > button scrolls through menus, items, and
options in a circular fashion. Pressing the < > and < > buttons
simultaneously displays the default values.
• To use the Secure/Sample Print feature, additional memory of 256 MB or
above (optional) must be installed.
7 <Error> lamp Blinks or lights when an error occurs.
8 <Ready> lamp Lights when the printer is ready to print.
