42 2 Basic Operation
11
13
12
15
14
Back
No. Name Description
11 Parallel connector (option) Installing a Parallel Port (option) allows connection of a Centronics interface
cable.
12 USB 2.0 connector Allows connection of a USB 2.0 cable.
13 Ethernet connector Allows connection of a 10Base-T/100Base-TX Ethernet interface cable.
14 Expansion device connector Allows connection of expansion devices supported by the printer.
15 Power cord connector Connects the power cord to the printer.
To Next Page
