98 4 Paper
Loading paper into Trays 1 through 4
The following example shows how to load paper into Tray 1. Use the same procedure to
load paper into trays 2, 3, and 4.
Important
• Do not remove paper from or add paper to the paper trays during printing. Doing so can cause paper
jams.
• Make sure that the power is on when loading paper.
1. Pull out the tray until it stops.
2. Squeezing the top guide clip, slide it
towards the front of the tray.
3. Squeezing the side guide clip, slide it
towards the right side of the tray.
4. Load the paper with its print side facing up
and its leading edge aligned with the left
side of the drawer.
Important
• Do not load paper of different types into the tray. Doing
so can cause paper jams.
• Do not load paper above the maximum fill-line. Doing
so can cause paper jams.
To Next Page
