170 7 Maintenance
6. Remove the new drum cartridge out of the
box and take off the protective sheet.
Important
• Do not touch the surface of the intermediate transfer
belt (black portion on the bottom) or the photosensitive
drum (blue portion on the back side). Scratches, dirt,
or oil from your hands can decrease print quality.
7. Hold the drum cartridge by the handles with
both hands. Gently insert the drum
cartridge into the printer, aligning the
projections marked with arrows on both
sides with the arrow labels on the printer.
8. Close the output tray cover and then the
front cover.
Important
• When closing the covers, be careful not to get your
fingers caught between the covers and the printer.
To Next Page
