General Procedures and Information
6-6 09/06 PHASER 3124 / PHASER 3125
Mechanical components specifications
Paper Feed
• Feed type : Multi-purpose feeder
• Feed method : Center loading
• Feed Qty : Cassette 250 sheets (75g/m
2
, 20lb paper standard)
• Manual 1 sheet bypass feeder : Paper, Transparencies, Envelope etc.
• Separation method
Cassette : Friction pad
Bypass feeder : N/A
• Drive mechanism : Main motor gearing
• Pick up roller driver : Solenoid
• Paper detection sensor : Photo sensor
• Paper size sensor : N/A
• Paper exit type : Faced Down
Transfer Assembly
The transfer roller transfers toner from the toner cartridge to paper.
Main Drive Assembly
The main drive assembly provides mechanical movement throughout the machine. The assembly
is powered by a single step motor.
Fuser
The fuser is consists of the heat lamp, heat roller, pressure roller, thermistor and thermostat.
It adheres toner on to paper with pressure and heat.
1. Heat Lamp
• Heat Lamp Terminal Type : Terminal single type
•Voltage
120 V : 115 +/- 5%
220 V : 230 +/- 5%
• Capacity : 750 Watt +/- 30 W
• Life : 3000 Hr.
2. Thermostat
• Thermostat Type : Non-contact type THERMOSTAT
• Control Temperature : 150 +/- 5°C
3. Thermistor
• Thermistor Model : FS-50004 (SEMITEC 364Fs Type)
• Temperature Resistance : 7 (180)
