Xerox Phaser 3124 Service Manual

Spare Parts List
PHASER 3124 / PHASER 3125 09/06 5-5
PL 2 Frame Assembly
Item Part Number Description Remark
0 LOWER FRAME UNIT
1 BASE FRAME
2 PAPER PATH ASSEMBLY
3 PAPER KNOCK-UP ASSEMBLY
4 007N01572 MAIN DRIVE ASSEMBLY
5 RIGHT PAPER GUIDE
6 LEFT PAPER GUIDE
7 GEAR PINION
8 120N00504 PAPER EMPTY ACTUATOR
9 OPC GROUND
10 RIGHT TORSION SPRING
11 LEFT TORSION SPRING
12 KNOCK-UP SPRING
13 ACTUATOR SPRING
14 FEED GEAR
15 SPRING
16 RUBBER FOOT

Xerox Phaser 3124 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	25 ppm
Internal memory	8 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	53 dB
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4
Power requirements	220 – 240 V, 50/60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	390 W
Power consumption (PowerSave)	6.5 W
Operating temperature (T-T)	10 - 32 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	358 x 298 x 253 mm
