Xerox Phaser 3124 Service Manual

General Procedures and Information
6-4 09/06 PHASER 3124 / PHASER 3125
Paper Handling Specifications
Standard Paper Capacity 250 Sheets
Paper Output 100 Sheets (faced down)
Duplexing Manual
Paper Weight: Plain paper 16 to 24 lb. Bond(60 to 90g/m2)
Thick stock 24 - 90 lb. Index(163g/m2)
Media Sizes Cassette A4, Letter, Folio, Legal, Executive, Statement, ISO B5, JIS B5,
A5
Manual A6, No. 10 Envelope, Monarch Envelope, DL Envelope, C5
Envelope, C6 Envelope, Transparency, Labels
Media Size 76 X 128mm (3 x 5”) to 216 X 356mm (8.5 X 14”)
Electrical Specifications
Power Save mode Yes
Energy Star Compliant Yes
Input Voltage Nominal input
voltage
110~127 VAC, 5.5 A
220~240 VAC, 3 A
Nominal fre-
quency
50/60 MHz
Power Consumption Printing 390W Ave. (Max.
400W)
400W Ave. (Max. 420W)
Ready (Idle) 65W 70W
Power Save 6.5W Ave. or less 8.5W Ave. or less
Environmental Specifications
Temperature Operating 10~32°C(50~90°F)
Non-Operating -20~40°C(-4~104°F)
Humidity: Operating 20% to 80% RH
Non-Operating 20% to 80% RH
Noise Level During opera-
tion
Sound Pressure: 53dB
Sound Power: 66dB
During
standby
Sound Pressure: 35dB
Sound Power: 66dB
Consumables Specifications
Toner Cartridge Yield Initial 1,000 sheets@ISO 5% coverage
Standard 3,000 sheets@ISO 5% coverage
Developing Method Non-magnetic Contact Developing
Charging Method Conductive Roller Charging
Toner Empty Sensor N/A
Cartridge Style Single cartridge
Table 1: Printer Specifications
Item Phaser 3124/B Phaser 3125/B Phaser 3125/N

Xerox Phaser 3124 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	25 ppm
Internal memory	8 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	53 dB
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4
Power requirements	220 – 240 V, 50/60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	390 W
Power consumption (PowerSave)	6.5 W
Operating temperature (T-T)	10 - 32 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	358 x 298 x 253 mm
