Xilinx 7 Series User Manual

238 www.xilinx.com 7 Series FPGAs GTP Transceivers User Guide
UG482 (v1.9) December 19, 2016
Appendix A: Placement Information by Package
CPG236 Package Placement Diagram
Figure A-1 show the placement diagram for the CPG236 package.
X-Ref Target - Figure A-1
Figure A-1: Placement Diagram for the CPG236 Package
B10 MGTREFCLK1P_216
A10 MGTREFCLK1N_216
B8 MGTREFCLK0P_216
A8 MGTREFCLK0N_216
B2 MGTPTXP1_216
UG482_aA_11_121916
A2 MGTPTXN1_216
B6 MGTPRXP1_216
A6 MGTPRXN1_216
D2 MGTPTXP0_216
D1 MGTPTXN0_216
B4 MGTPRXP0_216
A4 MGTPRXN0_216
XC7A12T:
GTPE2_COMMON_X0Y0
XC7A15T:
GTPE2_COMMON_X0Y0
XC7A25T:
GTPE2_COMMON_X0Y0
XC7A35T:
GTPE2_COMMON_X0Y0
XC7A50T:
GTPE2_COMMON_X0Y0
XC7A12T:
GTPE2_
CHANNEL _X0Y1
XC7A15T:
GTPE2_ CHANNEL _X0Y1
XC7A25T:
GTPE2_
CHANNEL _X0Y1
XC7A35T:
GTPE2_CHANNEL_X0Y1
XC7A50T:
GTPE2_CHANNEL_X0Y1
XC7A12T:
GTPE2_
CHANNEL _X0Y0
XC7A15T:
GTPE2_CHANNEL_X0Y0
XC7A25T:
GTPE2_
CHANNEL _X0Y0
XC7A35T:
GTPE2_CHANNEL_X0Y0
XC7A50T:
GTPE2_CHANNEL_X0Y0
