244 www.xilinx.com 7 Series FPGAs GTP Transceivers User Guide

UG482 (v1.9) December 19, 2016

Appendix A: Placement Information by Package

FBG484 Package Placement Diagram

Figure A-7 show the placement diagram for the FBG484 package.

X-Ref Target - Figure A-7

Figure A-7: Placement Diagram for the FBG484 Package

D7 MGTPTXP3_216

C7 MGTPTXN3_216

D9 MGTPRXP3_216

C9 MGTPRXN3_216

B6 MGTPTXP2_216

UG482_aA_04_021113

A6 MGTPTXN2_216

B10 MGTPRXP2_216

A10 MGTPRXN2_216

F10 MGTREFCLK1P_216

E10 MGTREFCLK1N_216

F6 MGTREFCLK0P_216

E6 MGTREFCLK0N_216

D5 MGTPTXP1_216

C5 MGTPTXN1_216

D11 MGTPRXP1_216

C11 MGTPRXN1_216

B4 MGTPTXP0_216

A4 MGTPTXN0_216

B8 MGTPRXP0_216

A8 MGTPRXN0_216

XC7A200T:

GTPE2_CHANNEL_X0Y7

XC7A200T:

GTPE2_CHANNEL_X0Y6

XC7A200T:

GTPE2_COMMON_X0Y1

XC7A200T:

GTPE2_CHANNEL_X0Y5

XC7A200T:

GTPE2_CHANNEL_X0Y4
