SBG484 Package Placement Diagram
SBG484 Package Placement Diagram
Figure A-8 show the placement diagram for the SBG484 package.
X-Ref Target - Figure A-8
Figure A-8: Placement Diagram for the SBG484 Package
D7 MGTPTXP3_216
C7 MGTPTXN3_216
D9 MGTPRXP3_216
C9 MGTPRXN3_216
B6 MGTPTXP2_216
UG482_aA_04_021113
A6 MGTPTXN2_216
B10 MGTPRXP2_216
A10 MGTPRXN2_216
F10 MGTREFCLK1P_216
E10 MGTREFCLK1N_216
F6 MGTREFCLK0P_216
E6 MGTREFCLK0N_216
D5 MGTPTXP1_216
C5 MGTPTXN1_216
D11 MGTPRXP1_216
C11 MGTPRXN1_216
B4 MGTPTXP0_216
A4 MGTPTXN0_216
B8 MGTPRXP0_216
A8 MGTPRXN0_216
XC7A200T:
GTPE2_CHANNEL_X0Y7
XC7A200T:
GTPE2_CHANNEL_X0Y6
XC7A200T:
GTPE2_COMMON_X0Y1
XC7A200T:
GTPE2_CHANNEL_X0Y5
XC7A200T:
GTPE2_CHANNEL_X0Y4
