248 www.xilinx.com 7 Series FPGAs GTP Transceivers User Guide
UG482 (v1.9) December 19, 2016
Appendix A: Placement Information by Package
FFG1156 Package Placement Diagram
Figure A-11 through Figure A-14 show the placement diagram for the FFG1156 package.
X-Ref Target - Figure A-11
Figure A-11: Placement Diagram for the FFG1156 Package (1 of 4)
B19 MGTPTXP3_216
A19 MGTPTXN3_216
D18 MGTPRXP3_216
C18 MGTPRXN3_216
B21 MGTPTXP2_216
UG482_aA_07_021113
A21 MGTPTXN2_216
F19 MGTPRXP2_216
E19 MGTPRXN2_216
H20 MGTREFCLK1P_216
G20 MGTREFCLK1N_216
H18 MGTREFCLK0P_216
G18 MGTREFCLK0N_216
D22 MGTPTXP1_216
C22 MGTPTXN1_216
D20 MGTPRXP1_216
C20 MGTPRXN1_216
B23 MGTPTXP0_216
A23 MGTPTXN0_216
F21 MGTPRXP0_216
E21 MGTPRXN0_216
XC7A200T:
GTPE2_CHANNEL_X0Y7
XC7A200T:
GTPE2_CHANNEL_X0Y6
XC7A200T:
GTPE2_COMMON_X0Y1
XC7A200T:
GTPE2_CHANNEL_X0Y5
XC7A200T:
GTPE2_CHANNEL_X0Y4
