7 Series FPGAs GTP Transceivers User Guide www.xilinx.com 249

UG482 (v1.9) December 19, 2016

FFG1156 Package Placement Diagram

X-Ref Target - Figure A-12

Figure A-12: Placement Diagram for the FFG1156 Package (2 of 4)

B17 MGTPTXP3_116

A17 MGTPTXN3_116

F17 MGTPRXP3_116

E17 MGTPRXN3_116

B15 MGTPTXP2_116

UG482_aA_08_021113

A15 MGTPTXN2_116

D16 MGTPRXP2_116

C16 MGTPRXN2_116

H14 MGTREFCLK1P_116

G14 MGTREFCLK1N_116

H16 MGTREFCLK0P_116

G16 MGTREFCLK0N_116

D14 MGTPTXP1_116

C14 MGTPTXN1_116

F15 MGTPRXP1_116

E15 MGTPRXN1_116

B13 MGTPTXP0_116

A13 MGTPTXN0_116

F13 MGTPRXP0_116

E13 MGTPRXN0_116

XC7A200T:

GTPE2_CHANNEL_X1Y7

XC7A200T:

GTPE2_CHANNEL_X1Y6

XC7A200T:

GTPE2_COMMON_X1Y1

XC7A200T:

GTPE2_CHANNEL_X1Y5

XC7A200T:

GTPE2_CHANNEL_X1Y4

Send Feedback
