9. Maintenance
209
Replacement of Key Battery
1. Press the switch and remove the tailcap to the right.
2. At the arrow position, move lightly in opposite directions
from the top and bottom to pry open a snap, then use
a thin blade to slide back along the pried seam and pry
open the left side snap of the key cover.
3. At the arrow position, move lightly in opposite directions
from the top and bottom to pry open a snap.
4. At the arrow position, move lightly in opposite directions
from the top and bottom to pry open a snap, then use
a thin blade to slide back along the pried seam and pry
open the right side snap of the key cover. The key case is
opened.
