1. Notice to XPENG Owners
8
Front-drive intelligent power unit (IPU)
HV power distribution box
Traction battery. Refer to Page 9.
Vehicle Control Unit (VCU)
Charging port. Refer to Page 11.
Rear-drive intelligent power unit (IPU)
In-car 3-in-1 integrated power supply
Rear-drive motor
PTC heater
Front-drive motor
A/C compressor
EV System Layout
1 2 3 4 5 6 7
11 10 9 8
Warning
●
The orange wiring harnesses are HV ones. It is forbidden to touch or disassemble any HV wiring harnesses and related HV
parts, otherwise there is a danger of electric shock!
