10. Vehicle Specifications
1
2
3
4
5
6
7
8
9
10
11
223
Four-Wheel Alignment Parameters
The front and rear wheel alignment parameters are listed below (curb):
Item Name Parameter
Single-Sided Front Wheel Toe-In 0.188°±0.083°
Total Left and Right Wheel Toe-In 0.376°+0.083°
Single-Sided Front Wheel Camber Angle -0.45°±0.333°
Dierence in Camber Between Left and Right Wheels 0.333°
Single-Sided Kingpin Caster 6.5°±0.8°
Single-Sided Kingpin Inclination 7. 9 °
Single-Sided Rear Wheel Toe-In 0.186°±0.083°
Total Left and Right Wheel Toe-In 0.372°+0.117°
Rear Wheel Camber Angle -1.125°±0.333°
Dierence in Camber Between Left and Right Wheels 0.333°
Note: The kingpin inclination is not subject to tolerance requirements due to the large measurement deviation and the strong
correlation with the wheel camber angle, so it is only for reference.
