Yamaha DSP-A2 Owner's Manual

7
English
GETTING STARTED
Getting started
Remote controller User function stickers
Batteries (size AA, LR6, UM-3)
Unpacking
Carefully remove this unit and accessories from the box. You should find the unit itself and the following accessories.
Close the front cover whenever the controls inside the panel are not used.
To open the front cover
Opening and closing the front cover
To close the front cover

Yamaha DSP-A2 Specifications

General

Frequency Response	20Hz - 20kHz
Total Harmonic Distortion	0.015%
Type	AV Amplifier
Input Sensitivity	200 mV (Line)
Channel Separation	60 dB
Speaker Load Impedance	4-16 ohms
Video Connections	Composite, S-Video
Surround Sound Formats	Dolby Digital, DTS
Signal-to-Noise Ratio	100 dB
Dimensions	435 x 171 x 476 mm
Damping Factor	80 (8 ohms, 1kHz)
Digital Inputs	2 Coaxial
DSP Modes	Cinema DSP
Inputs	Phono
Outputs	Speaker Outputs
