6-13
E
LOWR
FORWARD GEAR AND DRIVE SHAFT
EXPLODED DIAGRAM
Step Procedure/Part name Q’ty Service points
8 Needle bearing 1
9 Tapered roller bearing outer race 1
10 Forward gear shim 1 set
Reverse the removal steps for installation.
