62Y5A11
5-50
1
2
3
4
5
6
7
8
9
4. Install the shift rod bolts
6
, shift rod
7
and power trim and tilt relay
8
.
5. Connect the pilot water hose
9
, trailer
switch coupler
0
(ET), warning indicator
coupler
A
(EHD), ground lead
B
(ET),
PTT motor leads
C
(ET), PTT relay
leads
D
(ET), 10-pin coupler
E
, and bat-
tery leads
F
.
6. Connect the throttle link rod
G
and fuel
hose
H
.
7. Connect the shift cable/shift rod
I
and
throttle cable
J
, and then adjust their
lengths. For adjustment procedures, see
Chapter 3, “Checking the throttle cable
operation,” and “Checking the gearshift
operation.”
T
R
.
.
Mounting bolt
4
:
21 N·m (2.1 kgf·m, 15 ft·lb)
Cylinder body
