BRKT
Bracket unit
7-49
62Y5A11
Checking the trailer switch
1.
Check the trailer switch for continuity.
Replace if out of specification.
Checking the trim sensor
1.
Measure the trim sensor resistance.
Replace if out of specification.
NOTE:
Turn the lever
1
and measure the resistance
as it gradually changes.
Lead color
Switch
positi
on
Sky blue
(Sb)
Red (R)
Light g
reen
(Lg)
Up
Free
Down
Trim sensor resistance:
Pink (P)
–
Black (B)
10
–
288.3
Ω
at 20
°
C (68
°
F)
217
219
