Yamaha FT50C - Power Trim and Tilt Motor

BRKT
Bracket unit
7-43
62Y5A11
Power trim and tilt motor
7
No. Part name Q’ty Remarks
1 Screw 3 M5
×
20 mm
2Yoke 1
3 O-ring 1
Not reusable
52.0
×
1.9 mm
4 Armature 1
5 Bushing 1
6 Screw 2 M4
×
12 mm
7 Wire lead 1
8Brush 2 1
9Brush 1 1
10 Brush holder 1
11 Circuit breaker 1
12 Brush spring 2
13 PTT motor base 1
14 Oil seal 1
Not reusable
