Yamaha FT50C - Clamp Brackets

62Y5A11
7-18
1
2
3
4
5
6
7
8
9
Clamp brackets
7
No. Part name Q’ty Remarks
1 Swivel bracket assembly 1
2 Screw 1 M6
×
15 mm ET model
3 Trim sensor 1 ET model
4 Trim sensor coupler 1 ET model
5 Plastic tie 1
Not reusable
6 Self-locking nut 2
7Cap 2
8Bolt 1 M6
×
25 mm
9 Anode 1
10 Port clamp bracket 1
11 Washer 2
12 Bushing 2
13 Through tube 1
14 Bolt 2 M6
×
25 mm
15 Anode 1
16 Ground lead 1
17 Grease nipple 1
18 Screw 1 M6
×
8 mm
19 Starboard clamp bracket 1
Upper case / Clamp brackets
