Yamaha FT50C - Page 144

LOWR
Lower unit
6-5
62Y5A11
Lower unit
6
No. Part name Q’ty Remarks
1 Lower unit 1
2 Plastic tie 1
Not reusable
3Hose 1
4 Check screw 1
5 Gasket 2
Not reusable
6 Dowel pin 2
7 Bolt 4 M10
×
40 mm
8 Drain screw 1
9Grommet 1
10 Bolt 1 M10
×
45 mm
11 Bolt 1 M8
×
60 mm
12 Thrust washer 1
13 Propeller 1
14 Washer 1
15 Washer 1
16 Cotter pin 1
Not reusable
17 Propeller nut 1
18 Trim tab 1
