Yamaha FT50C User Manual

62Y5A11
6-12
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Propeller shaft assembly 1
2 Propeller shaft housing assembly 1
3Ball 2
4 Slider 1
5 Shift plunger 1
6Cross pin 1
7 Dog clutch 1
8Spring 1
9 Propeller shaft 1
10 Washer 1
11 Straight key 1
12 Claw washer 1
13 Ring nut 1
14 Reverse gear 1
15 Thrust washer 1
16 Ball bearing 1
17 O-ring 1
Not reusable
86.8
×
5.5 mm
18 Propeller shaft housing 1
19 Needle bearing 1
20 Oil seal 2
Not reusable
Propeller shaft housing
