62Y5A11
7-4
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Tiller handle 1
2 Tiller handle wiring harness 1
3 Clip 1
4 Shift rod 1
5Nut 2
6 Bushing 1
7 Bolt 1 M12
×
70 mm
8 Clip 1
9 Throttle cable 1
10 Nut 1
11 Plastic washer 2
12 Metal washer 2
13 Wave washer 1
14 Pin 1
15 Gear 1
16 Throttle shaft 1
17 Bolt 1 M6
×
25 mm
18 Friction piece 1
19 Wing nut 1
20 Bolt 1 M6
×
25 mm
21 Gasket 1
22 Cover 1
23 Bolt 4 M5
×
14 mm
24 Bolt 1 M6
×
8 mm
25 Grease nipple 1
26 Case 1
27 Bushing 1
28 Spring 1
29 Washer 1
30 Throttle grip 1
31 Screw 1 M5
×
25 mm
Tiller handle
