Yamaha FT50C - Page 177

62Y5A11
7-8
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Shift rod assembly 1
2 Bottom cowling 1
3Bolt 1
4Spring 1
5Ball 1
6 Shift rod bracket 1
7 Cotter pin 1
Not reusable
8 Washer 1
9 Bushing 1
10 Bushing 1
11 Shift rod 1
12 Grommet 1
13 Rubber seal 4
14 Bolt 4 M6
×
30 mm
15 Grommet 4
16 Screw 1 M6
×
14 mm EHD model
17 Warning indicator 1 EHD model
18 Grommet 1 EHD model
19 Collar 4
20 Pilot water outlet 1
21 Plastic tie 2
Not reusable
22 Collar 2
23 Grommet 2
24 Bushing 2
25 Joint 1
26 Cowling lock lever 1
27 Pin 1
28 Cotter pin 2
Not reusable
29 Pin 1
30 Cotter pin 1
Not reusable
31 Bolt 2 Models with trailer switch
32 Bracket 1 Models with trailer switch
33 Trailer switch 1 Models with trailer switch
34 PTT motor lead 1 ET model
35 Trim sensor coupler 1 ET model
36 Screw 1 M6
×
24 mm ET model
37 Grommet 1
38 Rubber seal 1
39 Hose 1
Bottom cowling
