62Y5A11
7-28
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Power trim and tilt motor 1
2 Tilt cylinder end screw 1
3Bolt 3 M5
×
20 mm
4 O-ring 1
Not reusable
5 Joint 1
6 O-ring 1
Not reusable
7Ball 6
8 O-ring 1
Not reusable
28.7
×
3.5 mm
9 Free piston 1
10 Valve seal 1
11 Circlip 1
12 Circlip 1
13 Trim cylinder base 1
14 Spring 2
15 Plate 1
16 Circlip 1
17 Tilt cylinder assembly 1
18 O-ring 1
Not reusable
8.8
×
1.9 mm
19 Reservoir cap 1
20 Anode 1
21 Bolt 2 M6
×
25 mm
Tilt cylinder and trim cylinder
