Yamaha FT50C - Page 237

62Y5A11
8-18
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Clip 1
2 Pinion stopper 1
3Spring 1
4 Starter motor pinion 1
5 Upper bracket 1
6 O-ring 1
Not reusable
7 Washer 1 1
8Shim — As required
9 Washer 2 1
10 Armature 1
11 Stator 1
12 O-ring 1
Not reusable
13 Brush holder assembly 1
14 Brush set 1
15 O-ring 1
Not reusable
16 Washer 1
17 Spring washer 1
18 Nut 1
19 Lower bracket 1
20 Screw 2 M4
×
12 mm
21 Bolt 2 M5
×
125 mm
Starter motor
