Yamaha FT50C - Page 45

62Y5A11
2-10
1
2
3
4
5
6
7
8
9
Symbol Unit
Model
FT50CEHD
L1 mm (in) 576 (22.7)
L2 mm (in) 272 (10.7)
L3 mm (in) 797 (31.4)
L4 mm (in) 560 (22.0)
L5 (L) mm (in) 97 (3.8)
(X) mm (in) —
L6 (L) mm (in) 990 (39.0)
(X) mm (in) —
L7 mm (in) 397 (15.6)
L8 mm (in) 189 (7.4)
L9 (L) mm (in) 0.8 (0.03)
(X) mm (in) —
L10 mm (in) 63 (2.5)
H1 (L) mm (in) 917 (36.1)
(X) mm (in) —
H2 mm (in) 519 (20.4)
H3 mm (in) 191 (7.5)
H4 (L) mm (in) 536 (21.1)
(X) mm (in) —
H5 mm (in) 680 (26.8)
H6 (L) mm (in) 723 (28.5)
(X) mm (in) —
H7 mm (in) 330 (13.0)
H8 mm (in) 110 (4.3)
H9 mm (in) 738 (29.1)
H10 mm (in) 44 (1.7)
H11 (L) mm (in) 28 (1.1)
(X) mm (in) —
W1 mm (in) 181 (7.1)
W2 mm (in) 213 (8.4)
W3 mm (in) 181 (7.1)
W4 mm (in) —
W5 mm (in) 345 (13.6)
W6 mm (in) 738 (29.1)
A1 Degree 40
A2 Degree 63
A3 Degree 4
T1 mm (in) —
Maintenance specifications
