Yamaha FT50C - Page 47

62Y5A11
2-12
1
2
3
4
5
6
7
8
9
Symbol Unit
Model
FT50CED FT50CET
L1 mm (in) 576 (22.7)
L2 mm (in) 142 (5.6)
L3 mm (in) —
L4 mm (in) 560 (22.0)
L5 (L) mm (in) 97 (3.8)
(X) mm (in) —
L6 (L) mm (in) 990 (39.0)
(X) mm (in) —
L7 mm (in) 397 (15.6)
L8 mm (in) 149 (5.9)
L9 (L) mm (in) 0.8 (0.03)
(X) mm (in) —
L10 mm (in) 63 (2.5)
H1 (L) mm (in) 917 (36.1)
(X) mm (in) —
H2 mm (in) 519 (20.4)
H3 mm (in) 191 (7.5)
H4 (L) mm (in) 536 (21.1)
(X) mm (in) —
H5 mm (in) —
H6 (L) mm (in) 723 (28.5)
(X) mm (in) —
H7 mm (in) 330 (13.0)
H8 mm (in) 0.5 (0.02)
H9 mm (in) 738 (29.1)
H10 mm (in) 44 (1.7)
H11 (L) mm (in) 28 (1.1)
(X) mm (in) —
W1 mm (in) 181 (7.1)
W2 mm (in) —
W3 mm (in) 181 (7.1)
W4 mm (in) —
W5 mm (in) 345 (13.6)
W6 mm (in) —
A1 Degree 40
A2 Degree 63
A3 Degree 4
T1 mm (in) 560 (22.0)
Maintenance specifications
