Yamaha FT50C - Page 73

62Y5A11
4-4
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Fuel joint 1
2 Fuel filter 1
3 Fuel pump 1
4Bolt 1 M6
×
25 mm
5 Seal 1
6 Fuel hose 1 Fuel joint-to-fuel filter
7 Clip 3
8Bolt 1 M8
×
14 mm
9Nut 1
10 Bracket 1
11 Fuel hose 1 Fuel filter-to-fuel pump
205.0 mm (8.1 in)
12 Fuel hose 2 Fuel pump-to-carburetor
13 Clip 3
14 Bolt 2 M6
×
30 mm
15 O-ring 1
Not reusable
24.4
×
3.1 mm
16 Fuel filter cup 1
17 O-ring 1
Not reusable
32.2
×
2.0 mm
18 Fuel filter element 1
19 Body 1
20 Float 1
21 Screw 4 M5
×
35 mm
22 Cover 1
23 Fuel pump body 2 1
24 Fuel pump body 1 1
25 Nut 4
26 Plunger 1
27 Spring 1
28 Spring 1
29 Pin 1
30 Diaphragm 1
31 Screw 2 M3
×
6 mm
32 Valve 2
33 Nut 2
34 Seal 1
Not reusable
35 Gasket 1
Not reusable
Fuel filter and fuel pump
