62Y5A11
4-8
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Carburetor assembly 1 Joint-to-silencer
2 Clip 1
3 Blowby hose 1
4 Prime Start coupler 1
5Bolt 2 M6
×
30 mm
6Collar 2
7 Throttle link rod 1
8 O-ring 8
Not reusable
34.5
×
1.9 mm
9 Insulator 1
10 Dowel pin 2
11 Bolt 8 M6
×
25 mm
12 Fuel hose 2 Fuel pump-to-carburetor
13 Clip 2
14 Rivet 2
15 Acceleration pump 1
16 Screw 3 M5
×
9 mm
17 Link rod 1
18 Hose 1 Acceleration pump-to-acceleration pump
19 Hose 4 Acceleration pump-to-carburetor
20 Link rod 1
21 Carburetor 4
22 Silencer 1
23 Plastic tie 1
Not reusable
24 Blowby hose 1 Silencer-to-joint
25 Bolt 8 M6
×
90 mm
26 Collar 8
27 O-ring 4
Not reusable
37.7
×
3.5 mm
28 Plate 1
29 O-ring 4
Not reusable
34.5
×
1.9 mm
30 O-ring 4
Not reusable
31 Joint 1
Carburetor unit
