Yamaha FT50C - Page 85

62Y5A11
4-16
1
2
3
4
5
6
7
8
9
3. Open the throttle cam
2
slowly, and
check the engine speed when the accel-
eration pump stopper
3
comes into con-
tact with point
a
.
4. If out of specification, adjust the engine
speed at the operation point of dash-pot.
5. Open the throttle cam
2
slowly, and
check that the acceleration pump stopper
3
comes in contact with point
a
.
6. Turn the adjusting screw
4
in or out until
the specified engine speed is obtained.
7. Open and close the throttle cam a few
times, and check the engine speed at the
operation point of dash-pot again. Adjust
if necessary.
Digital tachometer: 90890-06760
Engine speed: 2,700 r/min
Carburetor
