62Y5A11
5-8
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Power trim and tilt relay 1 ET model
2Bolt 1 M8
×
16 mm
3 Negative battery lead 1
4 Wiring harness extension 1
5Grommet 1
6Nut 1
7 Spring washer 1
8 Positive battery lead 1
9 PTT relay positive lead 1 ET model
10 Fuse holder lead 1
11 Clip 1
12 Warning indicator coupler 1 EHD model
13 Trailer switch coupler 1 ET model
14 Plastic tie 1
Not reusable
15 Pilot water hose 1 110.0 mm (4.3 in)
16 Bolt 2 M6
×
20 mm
17 Neutral switch 1 Tiller handle models
18 Plate 1 Remote control models
19 Neutral switch lead 2 Tiller handle models
20 Ground lead 3
21 Bolt 1 M6
×
12 mm
22 PTT relay lead 2 ET model
23 Nut 2 ET model
24 Spring washer 2 ET model
25 PTT motor lead 2 ET model Green, blue
26 Bolt 2 M6
×
20 mm ET model
Power unit
